FRP Perforated Type Cable Tray
The FRP Perforated Type Cable Tray is manufactured from premium Fiber Reinforced Plastic (FRP) and is designed for light to medium-duty cable support applications. The perforated, solid-bottom construction provides excellent ventilation, heat dissipation, and convenient cable tie-down points, making it ideal for instrumentation, control, and power cable installations in corrosive and demanding environments.
Applications
FRP perforated cable trays provide safe, organized, and durable cable routing for a wide range of industrial applications.
- Power Plants & Electrical Substations: Organized cable management with excellent heat dissipation.
- Chemical & Industrial Plants: Resistant to chemicals, moisture, and corrosive environments.
- Offshore & Marine Installations: Suitable for humid and saltwater operating conditions.
- Railways & Transportation: Reliable routing for power, control, and signaling cables.
- Commercial & Infrastructure Projects: Used in industrial buildings, airports, metro stations, and commercial facilities.
Product Features
The perforated design allows proper airflow for heat dissipation while providing multiple cable tie-down points. Manufactured from high-quality FRP, these trays offer excellent corrosion resistance, electrical insulation, lightweight construction, UV resistance, and long-lasting performance with minimal maintenance.
| Model No. | Width (W) mm | Runner Height (H) mm | Thickness (T) mm | Load Bearing UDL (kg/mtr) |
|---|---|---|---|---|
| EPP-PT2 | 50 | 30 | 2.5 | 10 |
| EPP-PT22 | 50 | 50 | 3.0 | 11 |
| EPP-PT3 | 75 | 25 | 3.0 | 12 |
| EPP-PT4 | 100 | 50 | 4.0 | 15 |
| EPP-PT6 | 150 | 50 | 4.0 | 18 |
| EPP-PT8 | 200 | 50 | 4.0 | 25 |
| EPP-PT12 | 300 | 50 | 5.0 | 30 |
